Aggregated Oversize Four Side Moulder VH-M633V
Four Side Moulder VH-M633v is used for Heavy-duty processing , such as large type of wooden house beam and
wooden batten . All side planing , processing and shaping for oversize timber and large materials for wooden house .
| Touch screen All parameters can be set through interface . The interface supports the setting and displaying of Product information , tool date , width and thickness as well as the writing of Feeding speed and interval time of each spindle . |
| Intelligent automatic self-detection system helps to monitor
the operation of equipment at any time. |
| Tool Database |
| Any position can be set as the origin point |
| Model | VH-M633V | |
| Specification | Working width(mm) | 50-330 |
| Working thickness (mm) | 8-230 | |
| Working table length (mm) | 2000 | |
| Feeding speed (mm) | 6-36 | |
| Main spindle diameter (mm) | Φ 50 | |
| Main spindle revolution (r/min) | 6500 | |
| Air pressure (Mpa) | 0.6 | |
| Motor power (KW) | 1st Lower Shsft | 11kw/15HP |
| Right vertical spindle | 11kw/15HP | |
| Left vertical spindle | 11kw/15HP | |
| 1st Upper Shaft | 15kw/20HP | |
| 2nd Upper Shaft | 15kw/20HP | |
| 2nd Lower Shaft | 11kw/15HP | |
| Top spindle lifting | 0.55kw/0.75HP | |
| Feeding beam lifting | 0.75kw/1HP | |
| Feeding motor | 7.5kw/10HP | |
| Left vertical adjustment | 0.18kw/0.25HP | |
| Total power | 82.98kw/112.74HP | |
| Cutter diameter | 1st Lower Shsft | Φ 125-Φ 140 |
| Right Vertical spindle | Φ 125-Φ 200 | |
| Left vertical spindle | Φ 125-Φ 200 | |
| 1st Upper Shaft | Φ 125-Φ 200 | |
| 2nd Upper Shaft | Φ 125-Φ 200 | |
| 2nd Lower Shaft | Φ 125-Φ 200 | |
| Remark | Feeding wheel diameter | Φ140 |
| Dust outlet diameter | Φ140 |
One-button solution High quality touch control system
High-quality processing effects Boost efficiency and shorten the adjustment time sharply
